Salamander Super Casting Crucible

Salamander Super Casting Crucible

R1,600.00R1,700.00

A4 and A6 Crucibles Available.

Select size below

SKU: N/A Category: Tags: , , Brand:
Clear

Description

Salamander Super Crucibles

Salamander Super is a high quality ceramic bonded clay graphite crucible range manufactured by plastic forming techniques.

Applications

Salamander Super Crucibles are used to melt various metals, and provide consistent performance in fuel-fired furnaces and medium / high frequency induction furnaces. The smaller sizes are typically used to melt precious metals, while larger sizes can be used for some ferrous alloys such as grey iron as well as to melt non-ferrous alloys, such as Aluminium, Copper, Brass, and Bronze.

Typical Metal Casting Temperature

  • 850 – 1600°C (1562 – 2912°F)

Performance Characteristics

  • Clean melting
  • Good thermal conductivity
  • Good resistance to chemical corrosion
  • High refractoriness

Crucible Handling

A4 Specifications

  • Top Outside Dimension (TOD): 114mm
  • Bottom Outside Dimension (BOD): 76mm
  • Height (HT): 141mm
  • A4 Crucible holds just over 5kg of bronze
  • Brimful Capacity: 0.75 Litres
  • What’s in the Box: 2x A4 Crucibles

A6 Specifications

  • Top Outside Dimension (TOD): 130mm
  • Bottom Outside Dimension (BOD): 95mm
  • Height (HT): 165mm
  • A6 Crucible holds just over 9kg of bronze
  • Brimful Capacity: 1.20 Litres
  • What’s in the Box: 2x A6 Crucibles

Usage Instructions

Additional information

Weight N/A
Dimensions N/A
Crucible Size

A4 – Set of 2, A6 – Set of 2
